Preparing the batter
Note
every object can be treated like a layer, so the order in which components are put matters in case of overlapping objects.
Setting up the canvas
{
"duration": 1000,
"objects": [ <<< add the following objects here >>> ],
"size": {
"h": 750,
"w": 900
}
- The base canvas
{
"type": "shape",
"kind": "rectangle",
"color": "#eeccbe",
"comment": "Base canvas",
"opacity": 1,
"position": {
"x": -2,
"y": 0
},
"size": {
"h": 750,
"w": 900
}
}
- Adding Image canvas + shadow effect.
The shadow is just a displaced box of the same height (h) & width (w) but with offset position.
{
"type": "shape",
"kind": "rectangle",
"color": "#A9A9A9",
"comment": "image shador",
"opacity": 1,
"position": {
"x": 300,
"y": 155
},
"size": {
"h": 450,
"w": 550
}
},
{
"type": "shape",
"kind": "rectangle",
"color": "#ffffff",
"comment": "image canvas",
"opacity": 1,
"position": {
"x": 275,
"y": 130
},
"size": {
"h": 450,
"w": 550
}
}
- Adding an image
{
"comment": "Food image",
"opacity": 1,
"url": "https://lh3.googleusercontent.com/yf_qrvQ8TrrEVRmQTEnNmkFDhegNfceTE6zlJW_KpIKauA1mrHJLNNvNQJ9kC_Hzx2y3ebTmn9VlKEUQhYd0aKI",
"position": {
"x": 275,
"y": 130
},
"type": "image",
"size": {
"h": 450,
"w": 550
}
}
- Vertical & horizontal decorative 'line'
{
"type": "shape",
"kind": "rectangle",
"color": "#422e28",
"comment": "vertical decorative line",
"opacity": 1,
"position": {
"x": 230,
"y": 0
},
"size": {
"h": 200,
"w": 7
}
},
{
"type": "shape",
"kind": "rectangle",
"color": "#422e28",
"comment": "horizontal decorative line",
"opacity": 1,
"position": {
"x": 550,
"y": 650
},
"size": {
"h": 7,
"w": 450
}
}
- Main text
{
"comment": "Main text",
"opacity": 1,
"color": "#422e28",
"text": "Cuppie\ncakes",
"fontFamily": {
"name": "AbrilFatface-Regular",
"url": "https://assets.kubric.io/6e426b61-111f-4223-b73e-4808ee321772.ttf"
},
"fontSize": "60",
"position": {
"x": 150,
"y":300
},
"align": "center",
"type": "text",
"axis": 0
}
- Caption
{
"comment": "Header text",
"opacity": 1,
"color": "#be9371",
"text": "TODAY'S DESSERT",
"align": "center",
"fontFamily": {
"name": "Eczar semibold",
"url": "https://storage.googleapis.com/assetlib/db37ec98-482a-44bf-92c3-1c8a5e6e139c.ttf"
},
"fontSize": "30",
"position": {
"x": 700,
"y": 100
},
"type": "text",
"axis": 0
}
Baking the dish
Parameterize shot config parts of this design to have a customizable design
{
"duration": 1000,
"objects": [
{
"type": "shape",
"kind": "rectangle",
"color": "{{canvas-color}}",
"comment": "base canvas",
"opacity": 1,
"position": {
"x": -2,
"y": 0
},
"size": {
"h": "{{canvas-height}}",
"w": "{{canvas-width}}"
}
},
{
"type": "shape",
"kind": "rectangle",
"color": "#A9A9A9",
"comment": "image shadow",
"opacity": 1,
"position": {
"x": "[[275+20]]",
"y": "[[130+20]]"
},
"size": {
"h": "{{img-canvas-height}}",
"w": "{{img-canvas-width}}"
}
},
{
"type": "shape",
"kind": "rectangle",
"color": "#ffffff",
"comment": "image canvas",
"opacity": 1,
"position": {
"x": 275,
"y": 130
},
"size": {
"h": "{{img-canvas-height}}",
"w": "{{img-canvas-width}}"
}
},
{
"comment": "Food image",
"opacity": 1,
"url": "{{image-url}}",
"position": {
"x": 300,
"y": 150
},
"type": "image",
"size": {
"h": "{{img-canvas-height}}",
"w": "{{img-canvas-width}}"
}
},
{
"comment": "Main text",
"opacity": 1,
"color": "#422e28",
"text": "Cuppie\ncakes",
"fontFamily": {
"name": "AbrilFatface-Regular",
"url": "https://assets.kubric.io/6e426b61-111f-4223-b73e-4808ee321772.ttf"
},
"fontSize": "60",
"position": {
"x": 150,
"y": 300
},
"align": "center",
"type": "text",
"axis": 0
},
{
"comment": "Header text",
"opacity": 1,
"color": "#be9371",
"text": "TODAY'S DESSERT",
"align": "center",
"fontFamily": {
"name": "Eczar semibold",
"url": "https://storage.googleapis.com/assetlib/db37ec98-482a-44bf-92c3-1c8a5e6e139c.ttf"
},
"fontSize": "30",
"position": {
"x": 700,
"y": 100
},
"type": "text",
"axis": 0
},
{
"type": "shape",
"kind": "rectangle",
"color": "#422e28",
"comment": "vertical decoration line",
"opacity": 1,
"position": {
"x": 230,
"y": 0
},
"size": {
"h": 200,
"w": 7
}
},
{
"type": "shape",
"kind": "rectangle",
"color": "#422e28",
"comment": "horizontal decoration line",
"opacity": 1,
"position": {
"x": 550,
"y": 650
},
"size": {
"h": 7,
"w": 450
}
}
],
"size": {
"h": 750,
"w": 900
}
}
{
"canvas-color": {
"default": "#EECBCE",
"type": "text",
"title": "Canvas color"
},
"canvas-width": {
"default": 900,
"type": "text",
"title": "canvas width"
},
"canvas-height": {
"default": 750,
"type": "text",
"title": "canvas height"
},
"rectangle-color": {
"default": "#22B299",
"type": "text",
"title": "rectangle-color"
},
"image-url": {
"default": "https://lh3.googleusercontent.com/zZN2-3_0IFl-3laJpaqZ48qeQbDbQm7NWAQvRDHqu3q037C8gNACn1Qh_-_eSF2iye1bPJqEtuxfsrhPa5GEwl69",
"type": "text",
"title": "image URL"
},
"img-canvas-height": {
"default": 400,
"type": "text",
"title": "image canvas height"
},
"img-canvas-width": {
"default": 500,
"type": "text",
"title": "image canvas height"
}
}
Finally -
